| Tên thương hiệu: | UPE |
| Số mẫu: | VID0706A /VIC0750B |
| MOQ: | 5000 |
| Giá cả: | $1-$5 |
| Chi tiết đóng gói: | túi PE |
| Điều khoản thanh toán: | T/T |
| Component | Specification |
|---|---|
| Pogo pin | Brass, gold-plated surface (≤50mΩ contact resistance) |
| Plastic Housing | HTN + 30% UL94 V-0 black (high-temperature resistant) |
| Magnet | NdFeB permanent magnet (epoxy-coated option for salt spray resistance) |
| Outer Mold | Black TPE 80A (flexible, abrasion-resistant) |
| USB Connector | Stainless steel shell (USB 2.0) |
| Cable | 4-core, 1000mm long:
|
| Parameter | Value |
|---|---|
| Spring Force | 80g ± 20g @ 1.0mm height |
| Magnetic Adhesion Force | >550G |
| Service Life | 50,000 cycles min |
| Rated Voltage | 12V DC |
| Continuous Current | 3.0A |
| Peak Current | 4.0A (max) |
| Contact Resistance | ≤50mΩ |
| High-Voltage Test | AC/DC 1000V, 0.5mA, 3 sec |
Payment Term: T/T, 50% Deposit, 50% Balance
Payment method: T/T, PayPal, OCBC
Sample Lead Time: Inventory sample 2-3 Working day / Customized sample 5-7 Working day
Production Lead Time: 10-15 Working day
Made For: America, Europe, Asia, South African
Trade Term: EXW
Freight: Air, Sea, Express
Service: High quality with reasonable price, OEM service, any special size, color, designs are acceptable
